Guide B4 Noise and vibration control for building services systems (2016) (pdf)
Back To All Knowledge Items

Guide B4 Noise and vibration control for building services systems (2016) (pdf)

Standard Rate
£100.00  +VAT
Member Rate
FREE
Download
Standard Rate
£42.00  +VAT
Member Rate
£21.00  +VAT
Purchase

Guide B provides guidance on the practical design of heating, ventilation and air conditioning systems and is divided into six sections which are published separately:

B0: Applications and activities

B1: Heating

B2: Ventilation and ductwork

B3: Air conditioning and refrigeration

B4: Noise and vibration control for building services systems

Guide B Combined index

The full set is available at a discounted price here: Guide B (full set)

The PDF version of Guide B4 incorporates changes made to Figure 4.63 and Table 4.A1.1. Those who have purchased the print version should download the corrigenda here: Guide B4 Corrigenda (May 2022)


Topics covered in Guide B4: Noise and vibration control for building services systems include:​

  • Mechanisms of noise generation, noise sources and transmission paths
  • Summary of noise and vibration problems from HVAC
    • Typical sources of hvac noise and their characteristics
    • Transmission paths
    • Control of the transmission paths
  • Noise sources in building services
    • Fans
    • High velocity/high pressure terminal units
    • Grilles and diffusers
    • Fan coil units
    • Induction units
    • Air conditioning units
    • Fan-assisted terminal units
    • Rooftop units/air handling units
    • Acoustic louvres
    • Chillers and compressors
    • Pumps
    • Boilers
    • Heat rejection and cooling towers
    • Chilled ceilings
    • Lifts
    • Escalators
    • Electric motors
    • Noise from water flow systems
  • Noise control in plant rooms
    • Risk of noise induced hearing loss
    • Breakout noise from plant rooms
    • Break-in noise in plant rooms
    • Estimation of noise levels in plant rooms
  • Airflow noise – regeneration of noise in ducts
    • Flow rate guidance
    • Prediction techniques
    • Damper noise
    • Turbulence-induced noise in and from ductwork
  • Control of noise transmission in ducts
    • Duct components
    • Unlined straight ducts
    • Lined straight ducts
    • Duct bends
    • Duct take-offs
    • End reflection loss
    • Passive attenuators and plenums
    • Active attenuators
    • Use of fibrous sound absorbing materials in ducts
    • Duct breakout noise
    • Duct break-in noise
    • Attenuator noise break-in
  • Room sound levels
    • Behaviour of sound in rooms
    • Determination of sound level at a receiver point
    • Source directivity
    • Sound transmission between rooms
    • Privacy and cross talk
  • Transmission of noise to and from the outside
    • Transmission of noise to the outside and to other rooms
    • Transmission of external noise to the inside
    • Naturally ventilated buildings
  • Criteria for noise from building services systems
    • Objective
    • Choosing noise criteria parameters
    • Design criteria
    • Using dBA, dBC, NR and NC levels
  • Noise prediction of sound pressure levels from building services
    • Room effect
    • System noise
    • Breakout/break-in noise
    • Noise propagation to outdoors
  • Vibration problems and control
    • Fundamentals of vibration and vibration control
    • Rating equipment for vibration emission
    • Vibration isolation criteria
    • Common types of vibration isolator
    • Practical examples of vibration isolation
    • Noise in HVAC systems
    • Vibration in HVAC systems
  • Appendices
    • Explanation of some basic acoustic concepts
    • Regeneration of noise by duct components and terminations
    • Interpreting manufacturers’ noise data
    • Noise instrumentation
    • Vibration instrumentation
    • Uncertainty in measurement and prediction of sound levels and sound power levels
    • Application of noise prediction software and integrated building design processes

Acknowledgements:

Guide B4 Steering Committee: Bob Peters (Chair), Alan Fry Salex, Richard Galbraith, Peter Henson, Alex Krasnic, John Lloyd, John Shelton, Peter Tucker

Referees: Richard Cowell, Mark Saunders, Keith Shenstone
